MKP-630 Clamp Flat Membrane Pressure Transmitter

■ 316L stainless steel isolation diaphragm construction
■ High precision, all stainless steel structure
■ Strong anti-interference, good long-term stability
■ Zero point, full range can be adjusted
■ Diversified form structure, easy to install and use
■ A variety of aseptic process connection, applicable to process temperature up to 150 ° C
■ Flat embedded diaphragm surface roughness Ra <0.38μm

Ask A Quote

Product Description

Performance Parameters

Measurement Range	-100kPa…0~35kPa…2.5MPa
Pressure Type	Gauge Pressure, Absolute Pressure, Sealing Pressure
Power Output	4~20mA(12~30VDC) 0~10V(12~30VDC)
Precision	±0.5%FS
Storage Temperature	-40℃~125℃
Environmental Temperature	-20℃~85℃
Media Compatibility	Various media compatible with 316L compatible stainless steel
Temperature Drift	35kPa:±3%FS(0℃~60C) other:±1.5FS(-10℃~70C)
Protection Level	IP67

Range Selection

Range Code	Pressure Type	Measurement Range	Overload Pressure	Burst Pressure
35k	G	0~35kPa	300%FS	600%FS
70k	G	0~70kPa	300%FS	600%FS
100k	G、A	0~100kPa	200%FS	500%FS
250k	G	0~250kPa	200%FS	500%FS
600k	G	0~600kPa	200%FS	500%FS
1M	G	0~1MPa	200%FS	500%FS
1. 6M	G、 S	0~1. 6MPa	200%FS	500%FS
2. 5M	G、 S	0~2. 5MPa	200%FS	500%FS
