MKP-620 Threaded Flat Membrane Pressure Transmitter

■ 316L flat diaphragm construction for pressure connections
■ Hygienic, anti-scaling
■ Measurement of adiabatic pressure, gauge pressure and reference pressure of sealing
■ Good sealing, can work stably for a long time
■ High resistance to vibration and shock
■ Various output signals are available and can be customized according to customer requirements.

Ask A Quote

Product Description

Performance Parameters

Measurement Range	-100kPa…0~35kPa…10MPa
Pressure Type	Gauge Pressure, Absolute Pressure, Sealing Pressure
Power Output	4~20mA(12~30VDC) 0~5V、1~5V、0.5~4.5V、0~10V(12~24V)
Precision	±0.5%FS
Storage Temperature	-40℃~120℃
Operating Temperature	-40℃~85℃
Environmental Temperature	-20℃~85℃
Media Compatibility	Various media compatible with 316L compatible stainless steel
Temperature Drift	1.5%FS(-20℃~85℃)
Protection Level	IP65

Range Selection

MKP-620

Range Code	Pressure Type	Measurement Range	Overload Pressure	Burst Pressure	Seal
10k	G	0~10kPa	300%FS	600%FS	ED circle
20k	G	0~20kPa	300%FS	600%FS	ED circle
35k	G	0~35kPa	300%FS	600%FS	ED circle
70k	G	0~70kPa	300%FS	600%FS	ED circle
100k	G、A	0~ 100kPa	200%FS	500%FS	ED circle
160k	G、A	0~ 160kPa	200%FS	500%FS	ED circle
250k	G、A	0~250kPa	200%FS	500%FS	ED circle
400k	G	0~400kPa	200%FS	500%FS	ED circle
600k	G	0~600kPa	200%FS	500%FS	ED circle
1M	G、 S	0~ 1MPa	200%FS	500%FS	ED circle
1. 6M	G、 S	0~ 1. 6MPa	200%FS	500%FS	ED circle
2. 5M	G、 S	0~2. 5MPa	200%FS	500%FS	ED circle
4M	S	0~4MPa	200%FS	400%FS	ED circle
6M	S	0~6MPa	200%FS	400%FS	ED circle
10M	S	0~ 10MPa	200%FS	400%FS	ED circle
16M	S	0~ 16MPa	200%FS	400%FS	ED circle
25M	S	0~25MPa	150%FS	400%FS	ED circle
40M	S	0~40MPa	150%FS	300%FS	ED circle
60M	S	0~60MPa	150%FS	300%FS	ED circle
100M	S	0~100MPa	150%FS	300%FS	ED circle
N5k	omit	-100~250kPa	750kPa	1. 25MPa	ED circle
N7k	omit	-100~600kPa	1. 2MPa	3MPa	ED circle
N8M	omit	-0.1 ~1MPa	2MPa	5MPa	ED circle
N9M	omit	-0.1 ~1. 6MPa	3MPa	9MPa	ED circle
N10M	omit	-0.1 ~2. 5MPa	5MPa	12. 5MPa	ED circle

Note:G Gauge Pressure, A Absolute Pressure, S Seal Pressure

MKP-620H(High Pressure)

Range Code	Measurement Range	Overload Pressure	Burst Pressure
1. 6MS	1. 6MPa	135%FS	200%FS
2. 5MS	2. 5MPa	135%FS	200%FS
4MS	4MPa	135%FS	200%FS
6MS	6MPa	135%FS	200%FS
10MS	10MPa	135%FS	200%FS
16MS	16MPa	120%FS	150%FS
25MS	25MPa	120%FS	150%FS
40MS	40MPa	120%FS	150%FS
60MS	60MPa	120%FS	150%FS
100MS	100MPa	120%FS	150%FS
150MS	150MPa	120%FS	150%FS
